JIS F 7356 Bronze 5K lift check valves



Position: HOME > PRODUCTS > Marine > JIS Marine Valve > JIS F 7356 Bronze 5K lift check valves

JIS F 7356 Bronze 5K lift check valves

Standard: JIS F7301,7302,7303,7304,7351,7352,7409,7410
Pressure：5K,10K，16K
Size:DN15-DN300
Material：cast iron,cast steel,forged steel,brass,bronze
Type:globe valve,angle valve,
Media: Water,Oil,Steam

Tel: +86- 532- 55785171 / 55785172 / 55786571 / 55786572

E-mail: info@qdiflow.com

Description

DESIGN STANDARD		JIS F 7356-1996
TEST		JIS F 7400-1996
HYDRAULTC INSPECTION
TEST PRESSURE/MPA	BODY	1.05
	SEAT	0.77-0.4

Specification

4	GASKET	NON-ASBESTES
3	DISC	BC6
2	BONNET	BC6
1	BODY	BC6
NO.	NAME OF PART	MATERIAL
BRONZE 5K LIFT CHECK VALVE

Dimensions data(mm)

DN	d	L	D	C	NO.	h	t	H
25	25	120	95	75	4	12	10	77
32	32	140	115	90	4	15	12	81
40	40	160	120	95	4	15	12	91

DN	d	L	D	C	NO.	h	t	H
25	25	120	95	75	4	12	10	77
32	32	140	115	90	4	15	12	81
40	40	160	120	95	4	15	12	91

DN	d	L	D	C	NO.	h	t	H
25	25	120	95	75	4	12	10	77
32	32	140	115	90	4	15	12	81
40	40	160	120	95	4	15	12	91

DN	d	L	D	C	NO.	h	t	H
25	25	120	95	75	4	12	10	77
32	32	140	115	90	4	15	12	81
40	40	160	120	95	4	15	12	91
